Manual

The most popular option because automation control is only needed for the pop-up TV lift. To change the viewing angle, you simply need to grab the set and rotate to your desired position. No hunting for the remote.

Electric

The electric swivel interfaces with the user’s home control system and can be used as both electric and manual.

Product Information:

  • Swivel mechanism built into the design -- total stack-height of this combination only 5.25” high
  • All components (swivel (turret) bearing and associated support parts) are CNC machined, giving this automatic TV lift system extremely tight tolerances.
  • Bearing rotates smoothly on hard Delrin ball bearings, making the Pop-up TV Lift fully marine capable
  • Swivel precisely stops at the home position before lowering into the cabinet*
  • Safety slip clutch built in -- will “Slip” if someone accidentally bumps into the rotated TV*
  • Top quality electric motor - so quiet, it essentially can’t be heard*

*Electric features -- protect the rotation mechanism from damage and allow the user to manually swivel the lift if preferred

Features:

  • Our own proprietary low-profile turret bearing
  • Constructed of structural marine grade aluminum
  • Precision CNC machined throughout
  • Supports 500 plus pounds and has zero rattle
  • 115 volt Synchronous motor drive (electric version)
  • Absolute repeat center-detent feature (manual version)
  • Equipped with a 1/2" Aluminum cabinet support plate
  • 2 1/4" bore thru center for cable passage
  • Rugged marine capable duty
  • Package adds only 1 1/4" H to 4" W platform
